Angle Steel Telecom Tower Factory Quotation

The Angle Steel Telecom Tower is a full series of steel structure systems specifically designed for scenarios such as 4G/5G mobile communication, microwave transmission, radio and television broadcasting, public safety communication, and new energy supporting signal coverage.

It covers the main tower structure, antenna brackets, equipment supports, lightning rods, operating platforms, cable fixing supports, protective frames, and matching metal components.

The products are made of high-strength steel, precisely processed and treated with hot-dip galvanization for corrosion protection. They feature high strength, quick installation, strong corrosion resistance, long service life, and stable structure.

They can operate stably over the long term in complex environments such as extreme cold, high temperatures, high humidity, coastal salt spray, desert wind and sand, and heavy corrosion, fully meeting the design standards and safety requirements of domestic communication projects, new energy supporting projects, and overseas telecom projects.

As a comprehensive solution provider integrating design, manufacturing, testing, delivery, and operation and maintenance, Qingdao Anbang can provide customized Angle Steel Telecom Towers according to project coverage requirements, site conditions, equipment parameters, and environmental characteristics, helping projects shorten construction periods, reduce costs, and enhance signal stability and structural safety.

Product Core Structure

1. Main structure

Applicable height: 20m, 30m, 40m, 50m, 60m, 80m, 100m, 120m

Structural form: truss type, lattice structure, angle steel type

Core use: support antennas, transceivers, RRUs, cables and other communication equipment

Features: strong bearing capacity, wind and earthquake resistance, good overall rigidity, and convenient on-site assembly

2. Equipment holder

Applicable equipment: 4G/5G antennas, microwave antennas, transceivers, repeaters, RRUs, etc.

Structural form: single rod type, double rod type, frame type, platform type

Features: High precision, accurate docking, adaptation to the installation size of various communication equipment

3. Cable structure and support structure

Applicable: power cables, optical cables, feeder cables

Features: reasonable force, small deflection, and compliant communication safety distance

4. Lightning rod and lightning protection frame

Height: 3m–10m customized

Structure: single-tube lightning rod, lattice structure lightning rod, integrated lightning rod structure

Usage: Lightning protection of the whole tower, suitable for outdoor telecom base stations

5. Telecom tower operating platform, ladder and guardrail

Applicable: antenna maintenance platform, equipment operation platform

Standard: anti-slip, anti-rust, meet safety specifications

Features: Modularity, quick installation, high safety

6. Cable supports, clips and auxiliary steel structures

Material: hot-dip galvanized angle steel / channel steel

Usage: cable laying, feeder fixing

Advantages: anti-corrosion and durable, load standard, efficient construction

7. Customized structure for communication scenarios

Urban telecom angle steel tower

Rural & mountain signal coverage tower

Coastal anti-corrosion telecom tower

Gobi / desert wind-resistant telecom tower

High-altitude & low-temperature customized telecom tower

Product technical advantages

1. High-strength steel

Angle Steel Telecom Towers choose Q355B and Q420B high-quality structural steel, high tensile strength, deformation resistance, and overturning resistance, meet the requirements of extreme loads such as strong winds, ice and snow, and earthquakes.

2. CNC precision machining

Automatic CNC cutting, drilling, bending, hole position tolerance in millimeter level, high component matching degree, no need for secondary modification on site, greatly shortening the installation period.

3. Whole-process hot-dip galvanizing anti-corrosion

Anbang owns hot-dip galvanizing production line, zinc layer thickness far exceeds national standard, salt spray, wind and sand, chemical corrosion resistance, suitable for coastal, Gobi, chemical plants and other highly corrosive areas.

4. Strong customization ability

From 20m–120m full coverage, can optimize the structural scheme one-to-one according to terrain, equipment, meteorology and geological conditions.

5. Compliant with national and international standards

Our products have already passed national testing, meet GB, communication industry standards and international IEC related standards, can be used for various telecom and new energy projects at home and abroad.

Applicable scenarios

4G/5G mobile base stations (urban, rural, mountainous areas)

Radio and television signal transmission towers

Microwave communication link towers

Public safety & emergency command communication towers

New energy station supporting communication towers

Industrial parks, ports, mining area signal coverage

Coastal, saline-alkali land, Gobi, desert, high altitude harsh environment telecom towers

Overseas Telecom EPC Projects (Africa, Middle East, Southeast Asia, etc.)

Selection suggestions

Urban / Compact station: medium-height angle steel tower, small footprint and beautiful appearance

Rural & mountain coverage: high-height lattice angle steel tower, high strength, long service life

Coastal salt spray area: strengthened hot-dip galvanizing + anti-corrosion optimization

Gobi wind and sand area: wind-resistant reinforced angle steel structure

Long-distance large coverage: 80m–120m high-strength lattice angle steel tower

Reasons for choosing Qingdao Anbang

● Full chain manufacturing capability

From design, blanking, processing, galvanizing to finished product testing, no outsourcing link, stable quality, controllable delivery time, avoiding supply chain risks.

● High strength and precision

Made of high-strength steel + CNC precision processing, high component accuracy, clear stress, large safety redundancy, reducing deformation, overturning and fracture risks, ensuring more assured long-term operation.

● Self-owned galvanizing factory

Equipped with professional hot-dip galvanizing production line, uniform zinc layer, strong adhesion, anti-corrosion life far exceeds peers, greatly reducing later maintenance costs.

● Customized solutions to suit all scenarios

Can be designed one-to-one according to height, equipment, terrain and environment, providing wind-resistant, anti-corrosion, large-span and other special structures.

● Complete authoritative certification

Passed ISO9001/ISO14001/ISO45001 system certification and equipped with national structural test report, meeting bidding requirements of communication, new energy and overseas projects.

● Fast response and efficient delivery

Anbang can provide quotations, drawings and technical solutions 24 hours a day, short production cycle, standardized packaging and convenient transportation, supporting urgent project schedule.

● Full life cycle service guarantee

From early planning to on-site installation guidance and later operation and maintenance, provide one-stop long-term service, truly realizing "one cooperation, whole process at ease".

● Cost-effective

Reasonable structure, accurate material usage, efficient installation, reducing procurement, construction and maintenance costs, significantly better than similar products.
