Professional Tension Tower Factory Direct

Tension towers are the core load-bearing components of overhead transmission lines. They are mainly used to anchor conductors in sections, control line tension, divide tension sections, limit the spread of wire break accidents, and ensure the safe and stable operation of transmission lines.

Qingdao Anbang New Energy, as a national high-tech enterprise, a reliable manufacturer and supplier in China, focuses on the research, development, manufacturing, and full-process service of tension towers. Our products cover all voltage levels from 35kV to 220kV and include various types such as angle steel tension towers and steel pipe tension towers.

Strictly following the general design specifications of the State Grid, the towers are suitable for main grid lines, crossings of roads and rivers, and complex terrains such as mountains and hills. They are widely used in domestic grid upgrades, rural network transformations, and supporting new energy transmission projects. With fine quality and efficient service, the company has become a preferred supplier for power engineering projects.

Product Subdivision

1. Low/Medium Voltage Tension Towers (35kV)

35kV Straight Line Tension Towers

35kV Lightweight Double-Circuit Tension Towers

Mountain Narrow-Base Tension Towers

2. High Voltage Tension Towers (110kV)

110kV Dry-Type Tension Towers

110kV Drum-Type Tension Towers

Single Circuit Reinforced Tension Towers

Double Circuit Heavy Load Tension Towers

3. Ultra High Voltage Tension Towers (220kV)

220kV Conventional Load-Bearing Tension Towers

Long-Span Heavy Load Tension Towers

Special Tension Towers for Line Crossings

4. Special Derivative Tension Towers (Towers of the Same System)

Small Angle Tension Towers (0°~20°)

Terminal Tension Towers (Dedicated for Start and End of Lines)

Angle Steel Combined Tension Towers

Steel Pipe Composite Tension Towers

Core Product Advantages

1. Strong load-bearing structure

The tower body uses a thickened angle steel truss structure, with larger component specifications and denser bolted joints. The overall stiffness, tensile resistance, and anti-overturning performance far exceed conventional straight towers.

It can evenly bear the bidirectional tension of conductors and ground wires, effectively segment tension areas, lock line tension under wire breakage or tightening conditions, prevent accident propagation, and ensure overall line safety.

2. National standard precision manufacturing

Strictly follows the "Steel Structure Design Standard" and "General Design of Transmission Line Towers." High-quality national standard carbon structural steel is selected for raw materials.

CNC cutting, precision punching, and automated welding ensure accurate dimensional tolerances and high fit of tower assembly.

Factory load verification and stress testing are fully covered, meeting grid connection acceptance standards.

3. Long service life

All tower components adopt overall hot-dip galvanization, with a uniform and dense zinc layer offering strong resistance to acid rain, coastal salt spray, and corrosion in humid mountainous areas.

No frequent rust removal or repainting is needed, and outdoor service life can reach 50 years, reducing full-cycle operation and maintenance costs.

4. Strong customization capability

Suitable for flat land, hills, mountains, marshes, complex high-speed or river-crossing conditions. Tower height, cross-arm dimensions, leg spacing, and load levels can be customized as needed.

Adaptable to different weather conditions (high wind, icing, extreme cold) to meet diverse grid construction requirements.

5. Prefabricated modular design

The entire tower uses bolted assembly connections with no on-site welding. Standardized component segmentation allows easy transportation and fast on-site hoisting and assembly, significantly shortening project duration.

Accompanied by a full set of high-strength tension fittings and jumper structures, installation is standardized and worry-free.

6. Large-scale production capacity

Anbang is a Qingdao-based local power steel structure factory, covers 150,000㎡, producing over 50,000 tons of tower components annually.

Offers one-stop turnkey services including design, customized production, logistics, on-site installation, and after-sales maintenance, with ample stock and stable delivery cycles.

Structural Characteristics and Applicable Scenarios

● Structural Characteristics

Structurally adopts a short and sturdy reinforced design, with a steep tower slope and wide base section providing excellent torsion and uplift resistance. Reinforced tension cross-arms adapt to diagonal insulator string anchorage, with stable tension transfer, bearing vertical loads, horizontal wind loads, and longitudinal line tension, achieving integrated multi-load bearing.

● Applicable Scenarios

Typical applicable scenarios include:

Overhead transmission line sectional anchoring nodes

Long-distance line tension demarcation points

Both sides of significant crossings such as railways, highways, rivers, and canyons

Small-angle line transition sections

Grid terminal access points;

National and local grid renovation

Rural grid transformation

Photovoltaic/wind power supporting transmission projects.

Technical Specifications

Why Choose Anbang?

Qingdao Anbang New Energy possesses the qualifications of a national high-tech enterprise and a municipal-level green factory. Its products have passed authoritative quality inspections in the power industry, and come with complete quality inspection reports, material lists, and certificates of conformity.

We support foreign trade exports as well as domestic power grid project bidding. Upholding the philosophy of 'Meticulous Craftsmanship in Tower Building, Integrity for Long-term Success,' Anbang focuses on the field of tension towers, striving to strengthen the safety foundation for various transmission projects.

We support custom drawings, tower type optimization, batch supply, and turnkey project services.

We welcome customers to request detailed tower drawings, product quotations, and technical solutions, and to join us in building a safe, efficient, and green transmission network.
