Power Transmission Tension Tower

The Qingdao Anbang New Energy Power Transmission Tension Tower is a core support equipment suitable for 110kV-1000kV high-voltage and ultra-high-voltage transmission lines, also known as a tension tower or angle tower. Choose us as your manufacturer and supplier, we can offer one-stop solutions worldwide.

Our tower follows the GB/T 2694-2018 manufacturing standard and uses a high-strength angle steel lattice structure, specifically designed for line turns, sectionalization, and terminal points. It can efficiently bear conductor tension, withstand extreme conditions, and achieve stable anchoring and safe transmission of the power line.

Power Transmission Tension Towers are widely used in long-distance cross-region transmission, new energy gathering and delivery, and backbone power grid construction projects. With advantages such as high stability, long-lasting corrosion resistance, and convenient installation, they have become key equipment to ensure the safe and economic operation of the power grid, highlighting the strength of Chinese intelligent manufacturing.

Core Advantages

High-strength load resistance

The main materials of the transmission tension tower are Q355B and Q420B high-strength angle steel, with a lattice truss structural design that ensures uniform and reasonable stress distribution.

It can effectively bear the axial tension of conductors, wind load, ice load, and seismic effects, and can accommodate line angle requirements from 2° to 30°.

The structural stability far exceeds industry standards, eliminating the risk of progressive collapse of the lines and ensuring the safety of the transmission lines.

Long-lasting maintenance-free

The transmission tension tower adopts a dual anti-corrosion system of hot-dip galvanization and epoxy powder coating, strictly following the GB/T 13912 standard requirements.

The anti-corrosion service life is ≥30 years, making it suitable for harsh outdoor environments such as coastal areas, saline-alkali land, and high-cold mountainous regions, significantly reducing the full lifecycle operation and maintenance costs of transmission tension towers and minimizing later repair investments.

Standardized prefabrication and convenient installation

The Power Transmission Tension Tower is fully factory-standardized prefabricated, with component accuracy controlled within ±0.5mm, strictly manufactured according to GB/T 2694-2018 technical conditions.

On-site assembly uses bolt connections without the need for complex construction equipment, enabling rapid assembly, significantly shortening construction cycles, improving project efficiency, and adapting to various terrain installation requirements.

Customizable adaptation

The structure, dimensions, and specifications of the transmission tension tower can be customized according to line voltage levels, turn angles, terrain conditions, and load requirements.

It covers multiple configurations including cup type, owl head type, and “dry” type, adaptable to AC/DC transmission systems of different types, meeting the tension bearing requirements for lines from 110kV to 1000kV, and suitable for complex environments such as deserts, mountains, and coastal areas.

High-level protection

The transmission tension tower has a seismic resistance rating of 7–8, meeting GB 50260 standards, with protection levels of IP23–IP54.

It exhibits excellent wind resistance, ice resistance, and lightning protection, able to withstand strong wind loads of 0.35KN/m²–0.75KN/m² and 8mm ice conditions, ensuring stable operation under extreme weather and maintaining uninterrupted transmission line performance.

Principle of Product Function

As the "rigid anchoring node" of a transmission line, the core function of a Power Transmission Tension Tower is to bear conductor tension, balance the forces on the line, and ensure the stable operation of the transmission line. The principle of its function is mainly reflected in three aspects:

First, tension bearing and anchoring. The transmission tension tower fixes the conductors through the tower head cross arm and strain insulator strings, receiving and balancing the axial tension on both sides of the conductor at line turns, segmentations, or terminal positions, preventing conductor stretching or detachment, avoiding line displacement, and providing rigid support for the line.

Second, force balance and transmission. The lattice angle steel structure of the transmission tension tower is designed through professional mechanical simulation to evenly transmit various forces such as conductor tension, wind load, and ice load to the tower foundation, preventing local stress concentration, avoiding tower deformation or damage, and ensuring long-term structural stability of the tower.

Third, optimizing line layout. By means of reasonable angle design and structural configuration, the transmission tension tower enables line turning and segment control, balances line parameter asymmetry, reduces additional line loss and electromagnetic interference, and ensures a safe distance between conductors and the ground or buildings, meeting the requirements of DL/T5352-2018 standards and ensuring transmission safety and power quality.

Our Services

Customized Solution Design

Relying on a professional R&D team and engineering experience, combined with clients' transmission line parameters, terrain conditions, and load requirements, we provide exclusive structural design, tension calculation, angle scheme optimization, and overall technical consulting services for transmission tension towers, ensuring that the towers precisely match engineering needs.

One-Stop Manufacturing

Qingdao Anbang has a modern self-owned factory, achieving full-chain control of transmission tension towers from raw material procurement, cutting, welding, corrosion protection treatment to finished product inspection.

Every procedure strictly follows the GB/T 2694-2018 standard and undergoes nondestructive testing to ensure tower quality meets standards.

On-Site Technical Support

We offer on-site installation guidance, procedure explanation, technical commissioning, and other services for transmission tension towers, dispatching professional technicians to assist in resolving various issues during construction, ensuring towers are installed according to standards and efficiently put into operation.

Full-Cycle After-Sales Guarantee

Power Transmission Tension Towers come with a ≥30-year warranty. We have established a comprehensive after-sales follow-up mechanism, regularly inspecting the operational status of products, providing lifelong technical support and emergency repair services, responding promptly to client needs, and ensuring long-term stable operation of the towers, reducing clients' operation and maintenance risks.

Product Specifications
