Steel Monopole Cable Termination Tower

The steel monopole cable termination towers produced by Qingdao Anbang New Energy are made from carefully selected Q235B/Q355B high-quality steel and utilize a high-standard hot-dip galvanizing anti-corrosion process.

They are key equipment for achieving reliable connections between overhead lines and underground cables in power transmission systems.

Leveraging full-process quality control in our own factory, the products feature structural stability, excellent mechanical performance, corrosion resistance, durability, and ease of installation.

They can adapt to various power engineering scenarios and support customizable production of multiple specifications.

We provide customers with a one-stop solution integrating design and R&D, manufacturing, on-site installation, and operation and maintenance services.

Our products are widely used in domestic high-voltage transmission networks, municipal power facilities, industrial park power supply, and other key projects, effectively ensuring the safe transfer and stable transmission of electricity, providing solid support for the efficient and reliable operation of the power grid.

Core strengths

Factory direct supply

Its own 50,000 square meters of modern production base, annual output of more than 50,000 tons of various power steel components, steel single column cable termination tower from raw material procurement, steel cutting, welding and forming to hot-dip galvanizing anti-corrosion.

The whole process of independent control, refusal to outsource, each steel single column cable termination tower has been strictly tested to ensure uniform specifications, stable performance, greatly reduce the cost of intermediate links, cost-effective supply, and meeting the bulk procurement needs of various power projects.

Super anti-corrosion

Adopting a high-standard hot-dip galvanizing process, the thickness of the zinc layer ≥ 85μm, far exceeding the requirements of the national standard.

The zinc-iron alloy layer is combined with the metallurgy of the steel matrix, the adhesion is extremely strong, not easy to fall off, not rust, can effectively resist coastal salt spray, high temperature humidity, industrial corrosion and other complex environmental erosion.

In the ordinary environment anti-corrosion life of more than 30 years, greatly reduce the maintenance cost of the whole life cycle of steel single-column cable termination towers.

Safety and reliability

the selection of high-strength steel, after precision welding and forming process, the weld seam is full and uniform, without flaws, the wind resistance level is ≥ 12, the overturning coefficient is ≥ 1.5.

The bottom flange and stiffener plate reinforcement design, the bearing capacity is strong, it can stably support cable termination heads, lightning arresters and other equipment, adapt to the needs of high-voltage and ultra-high-voltage power transmission, and prevent the deformation and dumping of steel single-column cable termination towers caused by extreme weather or equipment load, so as to ensure the safety of power transmission.

Flexible customization and wide adaptation

According to the voltage level, transmission capacity, and installation scenarios of power engineering, steel single-column cable termination towers with different heights, pipe diameters, and wall thicknesses can be customized to meet various voltage levels such as 110KV and 220KV.

It can be applied to different scenarios such as urban main roads, industrial parks, along highways, and around bridges, and at the same time support the integration of OPGW optical cables, monitoring equipment and other functions to meet diverse power transmission supporting needs.

Compact footprint and convenient construction

Compared with traditional transmission towers, steel single-column cable termination towers have a compact structure and small footprint, only about 1/3 of the area occupied by traditional towers.

The prefabricated production of rods and on-site installation do not require complex tower assembly processes, which can greatly shorten the construction period, improve construction efficiency and reduce construction costs.

How the product works

As a key connection equipment in the power transmission system, the core role of the steel single-column cable termination tower is to realize the safe connection and power conversion between overhead lines and cable lines, and its working principle revolves around the stability and safety of power transmission.

First of all, the steel single-column cable termination tower is firmly connected to the ground through the bottom fixed foundation, a stable support platform is built, and the cable termination bracket is installed in the designated position of the tower.

Secondly, through the insulation support leads, the underground cable and the overhead line are accurately connected to achieve the smooth transmission of power from the cable to the overhead line, or from the overhead line to the cable, and at the same time bear the tension between the cable and the overhead wire, ensure that the wire maintains a safe distance from the ground and other objects, and prevent potential safety hazards such as current leakage and short circuit.

In addition, steel single-column cable termination towers can effectively protect cable terminations, lightning arresters and other equipment, resist external environmental influences such as wind and rain, lightning, corrosion, etc., ensure the stability and efficiency of the power transmission process, and provide core support for the safe operation of the power system.

Our services

Design consultation

The professional and technical team combines the voltage level, transmission requirements, and installation scenarios of power engineering to provide steel single-column cable termination tower selection, load calculation, and structural optimization design.

Issue scheme drawings that meet the actual needs of the national standard and the project, assisting customers to avoid design risks, optimize construction costs, and ensure that the steel single-column cable termination tower is adapted to the overall power project.

Customized production

Relying on its own factory, it supports mass production and personalized customization of steel single-column cable termination towers, strictly controls the production cycle.

We can adjust materials, specifications, and processes according to customer needs, adapt to the use needs of different voltage levels and different scenarios, and ensure on-time delivery and quality standards.

Installation guidance

Provide on-site installation technical guidance and personnel training, assist customers in completing the foundation construction, rod hoisting, equipment installation and commissioning of steel single-column cable termination towers.

Standardize the installation process, ensure stable and compliant installation, solve various technical problems in the installation process, and improve construction efficiency.

After-sales guarantee

72-hour rapid response mechanism, provide regular inspection, maintenance, fault repair services, free replacement of non-man-made damaged parts during the warranty period of steel single column cable termination towers.

We provide lifelong technical support, timely investigation of equipment hidden dangers in the process of power transmission, and relieve customers' worries.

One-stop general contracting

It can undertake the design, production, installation and maintenance of steel single column cable termination tower general contracting services, integrate production, construction and after-sales resources, simplify the project process, reduce the comprehensive procurement and management costs of customers, and ensure the efficient promotion and smooth completion of power projects.

Real Cases

Qingdao West Coast New Area 220KV Power Supporting Project

Supplied over 30 steel monopole cable termination towers for this project, suitable for 220KV high-voltage power transmission requirements. For the coastal salt spray environment, a thick zinc layer anti-corrosion treatment was applied, and OPGW optical cable functionality was integrated.

After installation, the towers withstood multiple heavy rain and strong wind events without deformation or rust. The equipment operated stably, effectively achieving the safe connection between overhead lines and cables, and received high recognition from the power authorities.

Power Relocation Project on a Certain Section of Shandong Expressway

Customized 15 steel monopole cable termination towers for relocating a 110KV power line, suitable for narrow land scenarios along the expressway.

With the advantages of compact footprint and easy construction, the construction period was significantly shortened, ensuring that expressway construction and power transmission did not affect each other.

After three years of use, the steel monopole cable termination towers have shown stable performance with no equipment failures.

Jinan Industrial Park Power Upgrade Project

Supplied over 80 steel monopole cable termination towers, suitable for the industrial power transmission requirements of the park.

Specifications were customized based on the park's voltage level and equipment layout, integrating monitoring and lightning protection devices to ensure safe power transmission and real-time equipment monitoring. This supported the industrial park's power system upgrade and ensured stable electricity supply for enterprises.

Ningbo Yinzhou Economic Development Zone Power Supporting Project

Customized 4 dual-circuit steel monopole cable termination towers for this project, suitable for 110KV power line installation requirements, paired with high-standard hot-dip galvanizing process for the complex corrosive environment of the industrial park.

After installation, the towers efficiently achieved the connection between overhead lines and cables, ensuring safe electricity supply for enterprises and residents in the development zone, earning full recognition from the project parties.
