Power Substation Structure

Anbang New Energy in Qingdao, China, specializes in manufacturing power substation structures, centered on factory prefabrication and modular design, integrating high-strength steel structures with intelligent protection technologies.

Our products cover the full voltage range of 10kV-500kV. The power substation structures adopt standardized production and integrated design, efficiently supporting various electrical equipment, with excellent wind resistance, seismic resistance, corrosion protection, and protective performance, effectively adapting to complex outdoor conditions.

These power substation structures provide substations with load-bearing, protective, and integrated solutions, significantly shortening construction cycles, improving construction quality, supporting efficient grid construction and safe operation and maintenance, and serving as core foundational equipment to ensure the long-term stable and reliable operation of power substations.

Core Advantages

Factory-prefabricated, quality controllable: The structural components of the power substation are fully processed in Anbang's own factory in Qingdao under standardized production, with precision up to ±0.5mm. Welding and anti-corrosion processes meet national and international power grid standards, eliminating on-site processing errors and ensuring the overall stability.

Modular design, rapid deployment: The power substation structure is modularly divided and bolted on-site, shortening the installation cycle by 40% compared to traditional methods. It is suitable for complex environments such as urban areas, mountainous regions, and islands, significantly reducing the construction cost of power substations.

High strength and durability, safe and reliable: The structure uses high-strength steel Q355B or above, with an earthquake resistance level of 8. Anti-corrosion treatment adopts a dual process of hot-dip galvanizing and epoxy powder coating, with a service life of over 30 years, effectively resisting extreme weather and corrosive environments.

Integrated compatibility, supports diverse equipment: It reserves installation interfaces for transformers, switch cabinets, GIS equipment, and is compatible with intelligent monitoring and reactive power compensation systems, achieving seamless integration of substation equipment and structure.

Environmentally friendly and recyclable: The power substation structural components can be disassembled and recycled with a recovery rate of over 95%. Construction produces no dust and low noise, meeting the requirements of green power grid construction.

Product Function Principle

The structure of a power substation serves as the 'skeleton' of the substation. Its core function is to bear the self-weight and operational loads of key electrical equipment such as transformers, circuit breakers, and busbars, while ensuring the safe operation of electrical equipment through reasonable spatial layout and protective design.

The main structure adopts forms such as trusses, frames, and portal rigid frames. Using the principle of triangular stability to distribute loads, it evenly transfers equipment gravity, wind loads, and seismic loads to the foundation, avoiding localized stress concentration.

The power substation structure achieves electrical isolation between live equipment and grounded structures through insulated supports. Combined with the grounding network design, it provides discharge paths for fault currents and lightning currents, ensuring the safety of personnel and equipment.

Modular structures enable rapid installation and replacement of equipment through standardized interfaces, while also reserving space for ventilation, heat dissipation, and maintenance, ensuring a stable operating environment for the substation equipment.

Our Services

Customized Design: Provide 3D modeling, mechanical simulation, and optimized design services based on voltage levels, site conditions, and equipment parameters to meet users' personalized needs.

Factory Production: Undertake batch production of power substation structural components, strictly follow quality inspections, and complete pre-assembly before delivery to ensure zero installation errors on site.

One-Stop Installation: Provide turnkey services for on-site installation, commissioning, and acceptance of power substation structures, with a professional team ensuring installation quality and progress.

Full Lifecycle Operation and Maintenance: Provide operation and maintenance services, including regular inspection, anti-corrosion maintenance, and component replacement, to extend product lifespan.

Technical Support: 24/7 technical consultation, offering full-process technical guidance for the design, installation, and operation.
